BACK TO ALL PRODUCTSAbout the QualiShield® PH41
Our state-of-the-art scanning system is a non-destructive pinhole detection solution designed specifically to detect surface imperfections on aluminium foils. It detects pinholes, micro-leaks or pores anywhere in the inspection window, inspects base aluminium foils after forming, and checks lidding foils before sealing. And you can tailor it to the full range of format sizes available on blister-packaging machines.
Applications
Detection of pinholes, micro-leaks, and integrity failures in forming and lidding foils without damaging the material
| Features | Benefits | |
|---|---|---|
Detects pinholes with diameters as small as 25 μm | 100% real-time inspection of pores, fissures and pinholes on lidding and base foils | |
Compatible with aluminium foils of different widths and lengths | Assured performance, irrespective of aluminium foil types and sizes | |
Supports EudraLex Volume 4: Annex 11 compliance | Regulatory-compliant and audit-friendly | |
Can be set up for production and perform validation at the click of a button | User-friendly and compatible with a wide range of blister-packaging machines |
Features & Benefits
Detects pinholes with diameters as small as 25 μm
Detection sensitivity is adjustable to user requirements
100% real-time inspection of pores, fissures and pinholes on lidding and base foils
Compatible with aluminium foils of different widths and lengths
Assured performance, irrespective of aluminium foil types and sizes
Supports EudraLex Volume 4: Annex 11 compliance
Regulatory-compliant and audit-friendly
Can be set up for production and perform validation at the click of a button
User-friendly and compatible with a wide range of blister-packaging machines
Technical specifications
| Machine dimensions (with standard mounting) | Length | 321 mm | |
| Width | 63 mm | ||
| Height | 323 mm | ||
| Inspection area (FOV) | 200 mm | ||
| Type of packaging material inspected | Aluminium foil (non-transparent) | ||
| Reporting | Leak detection results, batch summaries and quality trends | ||
| Safety and interlocks | Safety guards, emergency stop switches and controlled access points | ||
| Regulatory compliance | Compliant with EudraLex Volume 4: Annex 11 | ||
